Earthquake Information
 Origin Time
2020-05-18 04:18:19 (GMT)
 Magnitude
M 4.7
 Latitude
34.2006° N
 Longitude
25.6533° E
 Focal Depth
5 km
 # of Arrivals
44
 Location 133.8 km SSE of Iraklion
168.5 km SE of Rethimnon
454.6 km SSE of Athens
 Solution type
manual
 Files / Links
QuakeML  GSE2.0  Alert  .phi  ShakeMap  Foc.Mech.


  Focal Mechanism

Foc.Mech. Strike (°) Dip (°) Rake (°) Seism.Mom. (dyn*cm)
917990 1.20E+23

Latitude (°N) Longitude (°E) Depth (km) Magnitude Mw
34.349725.61358.04.7

Source parameters determination

Click here for detailed focal mechanism solution


  Intensity map


PGA
PGV
MI

Download files: Google Earth (.kmz), Measurements (.csv)


  Station data

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
ZKRHL114.0 27 P04:18:38.50 -0.51.0M
ZKRHL114.0 27 S04:18:52.67 -0.61.0M
NPSHL118.0358 P04:18:38.72 -0.91.0M
NPSHL118.0358 S04:18:53.84 -0.41.0M
SIT2HI119.2 20 P04:18:39.15 -0.61.0M
SIT2HI119.2 20 S04:18:54.76 0.11.0M
STIAHC118.3 20 P04:18:39.00 -0.61.0M
STIAHC118.3 20 S04:18:53.67 -0.71.0M
IDIMN139.6330 P04:18:41.90 -0.81.0M
IDIMN139.6330 S04:18:59.53 -0.31.0M
GVDHL160.1297 P04:18:44.80 -0.81.0M
KARPHL203.3 42 P04:18:52.35 1.01.0M
KARPHL203.3 42 S04:19:16.31 0.61.0M
IMMVHL207.2313 P04:18:52.36 0.51.0M
SAP3HL250.1354 P04:18:57.37 0.11.0M
SAP3HL250.1354 S04:19:26.31 0.11.0M
SNT5HA246.1355 P04:18:57.30 0.51.0M
THERAHL241.4356 P04:18:56.05 -0.11.0M
ANKYHL283.2311 P04:19:02.14 0.71.0M
ANKYHL283.2311 S04:19:34.15 0.41.0M
MHLOHL299.1338 P04:19:03.34 0.01.0M
MHLOHL299.1338 S04:19:36.99 -0.21.0M
ARGHL316.8 44 P04:19:06.35 0.81.0M
APEHL319.6358 P04:19:05.67 -0.21.0M
APEHL319.6358 S04:19:42.08 0.41.0M
VLIHL372.0319 P04:19:11.90 -0.51.0M
VLIHL372.0319 S04:19:53.54 0.11.0M
SMGHL403.9 15 P04:19:15.70 -0.51.0M
KSLHL418.0 58 P04:19:18.19 0.11.0M
KARYHA439.8346 P04:19:20.88 0.21.0M
VLYHL439.1338 P04:19:20.73 0.11.0M
VLYHL439.1338 S04:20:08.67 0.41.0M
DIONHL457.9341 P04:19:22.87 -0.11.0M
PTLHL456.9340 P04:19:22.98 0.21.0M
PTLHL456.9340 S04:20:11.94 -0.31.0M
VLXHP459.8321 P04:19:23.24 0.01.0M
CHOSHT466.8 4 P04:19:24.02 0.01.0M
CHOSHT466.8 4 S04:20:15.25 0.91.0M
ITMHL472.2315 P04:19:24.32 -0.51.0M
VILLHA488.2335 P04:19:26.73 0.01.0M
GURHP510.9325 P04:19:29.47 -0.11.0M
GURHP510.9325 S04:20:24.75 0.51.0M
KYMIHL512.1345 P04:19:29.68 0.11.0M
KYMIHL512.1345 S04:20:25.32 0.91.0M


  Solution details

Event:
    Public ID              nkua2020jsly
    Type                   earthquake
    Description
      region name: Crete, Greece
Origin:
    Date                   2020-05-18
    Time                  04:18:19.47  +/-    0.4 s
    Latitude              34.2006 deg  +/-      3 km
    Longitude             25.6533 deg  +/-      2 km
    Depth                       5 km
    Agency                 HA
    Author                 A.Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.49 s
    Azimuthal gap             239 deg

2 Network magnitudes:
    MLv       4.73 +/- 0.16  23
    M         4.73           23 preferred

44 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    ZKR   HL    1.0  27  P       04:18:38.50  -0.5 M  1.0  ZKR
    ZKR   HL    1.0  27  S       04:18:52.67  -0.6 M  1.0  ZKR
    NPS   HL    1.1 358  P       04:18:38.72  -0.9 M  1.0  NPS
    NPS   HL    1.1 358  S       04:18:53.84  -0.4 M  1.0  NPS
    STIA  HC    1.1  20  P       04:18:39.00  -0.6 M  1.0  STIA
    STIA  HC    1.1  20  S       04:18:53.67  -0.7 M  1.0  STIA
    SIT2  HI    1.1  20  P       04:18:39.15  -0.6 M  1.0  SIT2
    SIT2  HI    1.1  20  S       04:18:54.76   0.1 M  1.0  SIT2
    IDI   MN    1.3 330  P       04:18:41.90  -0.8 M  1.0  IDI
    IDI   MN    1.3 330  S       04:18:59.53  -0.3 M  1.0  IDI
    GVD   HL    1.4 297  P       04:18:44.80  -0.8 M  1.0  GVD
    KARP  HL    1.8  42  P       04:18:52.35   1.0 M  1.0  KARP
    KARP  HL    1.8  42  S       04:19:16.31   0.6 M  1.0  KARP
    IMMV  HL    1.9 313  P       04:18:52.36   0.5 M  1.0  IMMV
    THERA HL    2.2 356  P       04:18:56.05  -0.1 M  1.0  THERA
    SNT5  HA    2.2 355  P       04:18:57.30   0.5 M  1.0  SNT5
    SAP3  HL    2.2 354  P       04:18:57.37   0.1 M  1.0  SAP3
    SAP3  HL    2.2 354  S       04:19:26.31   0.1 M  1.0  SAP3
    ANKY  HL    2.5 311  P       04:19:02.14   0.7 M  1.0  ANKY
    ANKY  HL    2.5 311  S       04:19:34.15   0.4 M  1.0  ANKY
    MHLO  HL    2.7 338  P       04:19:03.34   0.0 M  1.0  MHLO
    MHLO  HL    2.7 338  S       04:19:36.99  -0.2 M  1.0  MHLO
    ARG   HL    2.8  44  P       04:19:06.35   0.8 M  1.0  ARG
    APE   HL    2.9 358  P       04:19:05.67  -0.2 M  1.0  APE
    APE   HL    2.9 358  S       04:19:42.08   0.4 M  1.0  APE
    VLI   HL    3.3 319  P       04:19:11.90  -0.5 M  1.0  VLI
    VLI   HL    3.3 319  S       04:19:53.54   0.1 M  1.0  VLI
    SMG   HL    3.6  15  P       04:19:15.70  -0.5 M  1.0  SMG
    KSL   HL    3.8  58  P       04:19:18.19   0.1 M  1.0  KSL
    VLY   HL    3.9 338  P       04:19:20.73   0.1 M  1.0  VLY
    VLY   HL    3.9 338  S       04:20:08.67   0.4 M  1.0  VLY
    KARY  HA    3.9 346  P       04:19:20.88   0.2 M  1.0  KARY
    PTL   HL    4.1 340  P       04:19:22.98   0.2 M  1.0  PTL
    PTL   HL    4.1 340  S       04:20:11.94  -0.3 M  1.0  PTL
    DION  HL    4.1 341  P       04:19:22.87  -0.1 M  1.0  DION
    VLX   HP    4.1 321  P       04:19:23.24   0.0 M  1.0  VLX
    CHOS  HT    4.2   4  P       04:19:24.02   0.0 M  1.0  CHOS
    CHOS  HT    4.2   4  S       04:20:15.25   0.9 M  1.0  CHOS
    ITM   HL    4.2 315  P       04:19:24.32  -0.5 M  1.0  ITM
    VILL  HA    4.4 335  P       04:19:26.73   0.0 M  1.0  VILL
    GUR   HP    4.6 325  P       04:19:29.47  -0.1 M  1.0  GUR
    GUR   HP    4.6 325  S       04:20:24.75   0.5 M  1.0  GUR
    KYMI  HL    4.6 345  P       04:19:29.68   0.1 M  1.0  KYMI
    KYMI  HL    4.6 345  S       04:20:25.32   0.9 M  1.0  KYMI

28 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    ZKR   HL    1.0  27  MLv     4.57 -0.16    49.7013
    NPS   HL    1.1 358  MLv     4.62 -0.11    54.0104
    STIA  HC    1.1  20  MLv     4.62 -0.11    53.7407
    SIT2  HI    1.1  20  MLv     4.84  0.11    87.9321
    IDI   MN    1.3 330  MLv     4.43 -0.30    26.8451
    GVD   HL    1.4 297  MLv     4.64 -0.09    26.7518
    KARP  HL    1.8  42  MLv     4.45 -0.27    18.1533
    IMMV  HL    1.9 313  MLv     4.70 -0.03    22.9074
    THERA HL    2.2 356  MLv     4.66 -0.07    14.3372
    SNT5  HA    2.2 355  MLv     4.66 -0.07     8.0088
    SAP3  HL    2.2 354  MLv     4.74  0.01    25.8788
    ANKY  HL    2.5 311  MLv     4.66 -0.06    8.89583
    MHLO  HL    2.7 338  MLv     4.71 -0.02    16.6434
    ARG   HL    2.8  44  MLv     4.76  0.03    7.48806
    APE   HL    2.9 358  MLv     4.73 -0.00    6.76313
    VLI   HL    3.3 319  MLv     4.82  0.09    5.84081
    SMG   HL    3.6  15  MLv     4.92  0.19    4.08996
    KSL   HL    3.8  58  MLv     4.93  0.20    3.00011
    VLY   HL    3.9 338  MLv     4.97  0.24     3.8249
    KARY  HA    3.9 346  MLv     4.98  0.25    3.87062
    PTL   HL    4.1 340  MLv     4.97  0.24    3.48303
    DION  HL    4.1 341  MLv     4.33 -0.39    2.25903
    VLX   HP    4.1 321  MLv     4.49 -0.24    1.13673
    CHOS  HT    4.2   4  MLv     5.05  0.32    4.00075
    ITM   HL    4.2 315  MLv     4.90  0.17    2.73733
    VILL  HA    4.4 335  MLv     5.11  0.38    4.05151
    GUR   HP    4.6 325  MLv     5.14  0.41    3.88623
    KYMI  HL    4.6 345  MLv     5.10  0.37    3.56224
