Earthquake Information
 Origin Time
 2024-10-02 03:47:03 (GMT)
 Magnitude
 M 1.5
 Latitude
 38.4872° N
 Longitude
 21.9783° E
 Focal Depth
 13 km
 # of Arrivals
 34
 Location 28.0 km NNW of Aegion
34.4 km NE of Patras
163.2 km WNW of Athens
 Solution type
 manual
 Files / Links
 QuakeML  GSE2.0  Alert  .phi


  Station data

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
PYRGCL9.2159 P03:47:06.28 0.01.0M
PYRGCL9.2159 S03:47:08.49 -0.11.0M
EFPHP9.2223 P03:47:06.19 0.01.0M
EFPHP9.2223 S03:47:08.38 0.01.0M
ANXHP12.8337 P03:47:06.80 0.01.0M
ANXHP12.8337 S03:47:09.33 -0.11.0M
MALACL13.9222 P03:47:06.88 0.11.0M
MALACL13.9222 S03:47:09.88 0.51.0M
TRIZCL15.8149 P03:47:07.04 0.01.0M
TRIZCL15.8149 S03:47:09.84 0.11.0M
VVKHP16.2244 P03:47:07.11 -0.11.0M
VVKHP16.2244 S03:47:10.06 0.01.0M
KALEHA17.7127 P03:47:07.43 0.01.0M
KALEHA17.7127 S03:47:10.51 0.11.0M
PSAMCL25.7136 P03:47:08.41 -0.11.0M
PSAMCL25.7136 S03:47:12.31 0.01.0M
AGEOCL25.8163 P03:47:08.68 0.21.0M
AGEOCL25.8163 S03:47:12.18 -0.11.0M
DIMTCL27.3168 P03:47:08.98 0.31.0M
DIMTCL27.3168 S03:47:13.04 0.31.0M
LAKAHA27.5180 P03:47:08.72 -0.11.0M
LAKAHA27.5180 S03:47:12.86 -0.11.0M
GR241Y29.2 40 P03:47:09.22 0.11.0M
GR241Y29.2 40 S03:47:13.62 0.11.0M
DSFHP48.5100 P03:47:11.92 -0.21.0M
DSFHP48.5100 S03:47:18.77 0.01.0M
PLEVHP50.4261 P03:47:12.39 0.01.0M
PLEVHP50.4261 S03:47:19.17 0.01.0M
KLVHL51.6163 P03:47:12.28 -0.31.0M
KLVHL51.6163 S03:47:19.64 0.01.0M
DROHP63.9202 P03:47:14.46 -0.11.0M
DROHP63.9202 S03:47:23.48 0.51.0M
GURHP69.0152 P03:47:15.10 -0.31.0M
GURHP69.0152 S03:47:24.87 0.31.0M


  Solution details

Event:
    Public ID              nkua2024tisv
    Description
      region name: Greece
Origin:
    Date                   2024-10-02
    Time                  03:47:03.37
    Latitude              38.4872 deg  +/-      0 km
    Longitude             21.9783 deg  +/-      0 km
    Depth                      13 km   +/-    0 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.12 s
    Azimuthal gap              76 deg

2 Network magnitudes:
    MLv       1.47 +/- 0.18  13
    M         1.47           13 preferred

34 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    EFP   HP    0.1 223  P       03:47:06.19  -0.0 M  1.0  EFP
    EFP   HP    0.1 223  S       03:47:08.38  -0.0 M  1.0  EFP
    PYRG  CL    0.1 159  P       03:47:06.28  -0.0 M  1.0  PYRG
    PYRG  CL    0.1 159  S       03:47:08.49  -0.1 M  1.0  PYRG
    ANX   HP    0.1 337  P       03:47:06.80   0.0 M  1.0  ANX
    ANX   HP    0.1 337  S       03:47:09.33  -0.1 M  1.0  ANX
    MALA  CL    0.1 222  P       03:47:06.88   0.1 M  1.0  MALA
    MALA  CL    0.1 222  S       03:47:09.88   0.5 M  1.0  MALA
    TRIZ  CL    0.1 149  P       03:47:07.04   0.0 M  1.0  TRIZ
    TRIZ  CL    0.1 149  S       03:47:09.84   0.1 M  1.0  TRIZ
    VVK   HP    0.1 244  P       03:47:07.11  -0.1 M  1.0  VVK
    VVK   HP    0.1 244  S       03:47:10.06   0.0 M  1.0  VVK
    KALE  HA    0.2 127  P       03:47:07.43   0.0 M  1.0  KALE
    KALE  HA    0.2 127  S       03:47:10.51   0.1 M  1.0  KALE
    PSAM  CL    0.2 136  P       03:47:08.41  -0.1 M  1.0  PSAM
    PSAM  CL    0.2 136  S       03:47:12.31  -0.0 M  1.0  PSAM
    AGEO  CL    0.2 163  P       03:47:08.68   0.2 M  1.0  AGEO
    AGEO  CL    0.2 163  S       03:47:12.18  -0.1 M  1.0  AGEO
    DIMT  CL    0.2 168  P       03:47:08.98   0.3 M  1.0  DIMT
    DIMT  CL    0.2 168  S       03:47:13.04   0.3 M  1.0  DIMT
    LAKA  HA    0.2 180  P       03:47:08.72  -0.1 M  1.0  LAKA
    LAKA  HA    0.2 180  S       03:47:12.86  -0.1 M  1.0  LAKA
    GR24  1Y    0.3  40  P       03:47:09.22   0.1 M  1.0  GR24
    GR24  1Y    0.3  40  S       03:47:13.62   0.1 M  1.0  GR24
    DSF   HP    0.4 100  P       03:47:11.92  -0.2 M  1.0  DSF
    DSF   HP    0.4 100  S       03:47:18.77  -0.0 M  1.0  DSF
    PLEV  HP    0.5 261  P       03:47:12.39   0.0 M  1.0  PLEV
    PLEV  HP    0.5 261  S       03:47:19.17  -0.0 M  1.0  PLEV
    KLV   HL    0.5 163  P       03:47:12.28  -0.3 M  1.0  KLV
    KLV   HL    0.5 163  S       03:47:19.64   0.0 M  1.0  KLV
    DRO   HP    0.6 202  P       03:47:14.46  -0.1 M  1.0  DRO
    DRO   HP    0.6 202  S       03:47:23.48   0.5 M  1.0  DRO
    GUR   HP    0.6 152  P       03:47:15.10  -0.3 M  1.0  GUR
    GUR   HP    0.6 152  S       03:47:24.87   0.3 M  1.0  GUR

17 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    EFP   HP    0.1 223  MLv     1.55  0.08    1.64282
    PYRG  CL    0.1 159  MLv     1.33 -0.14   0.627886
    ANX   HP    0.1 337  MLv     1.51  0.04    1.23132
    MALA  CL    0.1 222  MLv     1.61  0.14    1.12609
    TRIZ  CL    0.1 149  MLv     1.56  0.09    1.15133
    VVK   HP    0.1 244  MLv     0.59 -0.88   0.563665
    KALE  HA    0.2 127  MLv     1.59  0.12    1.12173
    PSAM  CL    0.2 136  MLv     1.15 -0.33   0.253054
    AGEO  CL    0.2 163  MLv     1.27 -0.20   0.096238
    DIMT  CL    0.2 168  MLv     1.74  0.27   0.915628
    LAKA  HA    0.2 180  MLv     1.15 -0.32   0.229404
    GR24  1Y    0.3  40  MLv     1.60  0.13   0.585377
    DSF   HP    0.4 100  MLv     1.50  0.03   0.154473
    PLEV  HP    0.5 261  MLv     1.16 -0.31   0.0635894
    KLV   HL    0.5 163  MLv     1.70  0.23   0.155451
    DRO   HP    0.6 202  MLv     1.59  0.12   0.195843
    GUR   HP    0.6 152  MLv     1.69  0.22    0.11109
