Earthquake Information
 Origin Time
2023-11-20 02:05:01 (GMT)
 Magnitude
M 2.2
 Latitude
36.5992° N
 Longitude
25.7185° E
 Focal Depth
21 km
 # of Arrivals
24
 Location 32.6 km NE of Thira
64.0 km SSE of Naxos
233.5 km SE of Athens
 Solution type
manual
 Files / Links
QuakeML  GSE2.0  Alert  .phi


  Station data

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
CMBOHT31.4243 P02:05:07.02 0.11.0M
CMBOHT31.4243 S02:05:11.74 -0.11.0M
SNT1HA33.0232 P02:05:07.55 0.41.0M
SNT1HA33.0232 S02:05:11.98 -0.21.0M
THERAHL33.8220 P02:05:07.23 -0.11.0M
THERAHL33.8220 S02:05:12.03 -0.41.0M
SNT5HA36.2233 P02:05:07.78 0.21.0M
SNT5HA36.2233 S02:05:13.30 0.31.0M
SAP3HL38.0241 P02:05:07.96 0.11.0M
SAP3HL38.0241 S02:05:13.56 0.11.0M
APEHL55.5342 P02:05:09.81 -0.71.0M
APEHL55.5342 S02:05:17.92 -0.11.0M
NAX1HI63.7331 P02:05:11.27 -0.41.0M
NAX1HI63.7331 S02:05:20.36 0.21.0M
SERIHA126.2300 P02:05:21.45 0.11.0M
SERIHA126.2300 S02:05:37.31 0.21.0M
KNSSHC151.9199 P02:05:25.29 0.61.0M
KNSSHC151.9199 S02:05:43.16 0.11.0M
SMGHL157.9 39 P02:05:25.64 0.11.0M
SMGHL157.9 39 S02:05:44.34 -0.11.0M
IDIMN163.8207 P02:05:26.19 -0.11.0M
IDIMN163.8207 S02:05:45.40 -0.51.0M
GR271Y219.6323 P02:05:34.28 0.91.0M
GR271Y219.6323 S02:05:58.10 -0.21.0M


  Solution details

Event:
    Public ID              nkua2023wshp
    Description
      region name: Dodecanese Islands, Greece
Origin:
    Date                   2023-11-20
    Time                  02:05:00.53
    Latitude              36.5992 deg  +/-      1 km
    Longitude             25.7185 deg  +/-      1 km
    Depth                      21 km   +/-    1 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.29 s
    Azimuthal gap             160 deg

2 Network magnitudes:
    MLv       2.17 +/- 0.19  10
    M         2.17           10 preferred

24 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    CMBO  HT    0.3 243  P       02:05:07.02   0.1 M  1.0  CMBO
    CMBO  HT    0.3 243  S       02:05:11.74  -0.1 M  1.0  CMBO
    SNT1  HA    0.3 232  P       02:05:07.55   0.4 M  1.0  SNT1
    SNT1  HA    0.3 232  S       02:05:11.98  -0.2 M  1.0  SNT1
    THERA HL    0.3 220  P       02:05:07.23  -0.1 M  1.0  THERA
    THERA HL    0.3 220  S       02:05:12.03  -0.4 M  1.0  THERA
    SNT5  HA    0.3 233  P       02:05:07.78   0.2 M  1.0  SNT5
    SNT5  HA    0.3 233  S       02:05:13.30   0.3 M  1.0  SNT5
    SAP3  HL    0.3 241  P       02:05:07.96   0.1 M  1.0  SAP3
    SAP3  HL    0.3 241  S       02:05:13.56   0.1 M  1.0  SAP3
    APE   HL    0.5 342  P       02:05:09.81  -0.7 M  1.0  APE
    APE   HL    0.5 342  S       02:05:17.92  -0.1 M  1.0  APE
    NAX1  HI    0.6 331  P       02:05:11.27  -0.4 M  1.0  NAX1
    NAX1  HI    0.6 331  S       02:05:20.36   0.2 M  1.0  NAX1
    SERI  HA    1.1 300  P       02:05:21.45   0.1 M  1.0  SERI
    SERI  HA    1.1 300  S       02:05:37.31   0.2 M  1.0  SERI
    KNSS  HC    1.4 199  P       02:05:25.29   0.6 M  1.0  KNSS
    KNSS  HC    1.4 199  S       02:05:43.16   0.1 M  1.0  KNSS
    SMG   HL    1.4  39  P       02:05:25.64   0.1 M  1.0  SMG
    SMG   HL    1.4  39  S       02:05:44.34  -0.1 M  1.0  SMG
    IDI   MN    1.5 207  P       02:05:26.19  -0.1 M  1.0  IDI
    IDI   MN    1.5 207  S       02:05:45.40  -0.5 M  1.0  IDI
    GR27  1Y    2.0 323  P       02:05:34.28   0.9 M  1.0  GR27
    GR27  1Y    2.0 323  S       02:05:58.10  -0.2 M  1.0  GR27

12 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    CMBO  HT    0.3 243  MLv     2.24  0.08    2.29198
    SNT1  HA    0.3 232  MLv     1.68 -0.49   0.379653
    THERA HL    0.3 220  MLv     1.70 -0.47   0.568593
    SNT5  HA    0.3 233  MLv     1.94 -0.23   0.508713
    SAP3  HL    0.3 241  MLv     2.16 -0.01    2.12715
    APE   HL    0.5 342  MLv     2.10 -0.07   0.409293
    NAX1  HI    0.6 331  MLv     2.43  0.26   0.647725
    SERI  HA    1.1 300  MLv     2.06 -0.11   0.133586
    KNSS  HC    1.4 199  MLv     2.48  0.31   0.261086
    SMG   HL    1.4  39  MLv     2.26  0.09   0.147094
    IDI   MN    1.5 207  MLv     2.31  0.14   0.156938
    GR27  1Y    2.0 323  MLv     2.39  0.22   0.0989521
