Earthquake Information
 Origin Time
 2023-09-19 10:51:35 (GMT)
 Magnitude
 M 1.2
 Latitude
 38.7365° N
 Longitude
 21.7048° E
 Focal Depth
 4 km
 # of Arrivals
 21
 Location 7.5 km SSW of Karpenision
47.4 km NNE of Mesolonghi
195.7 km WNW of Athens
 Solution type
 manual
 Files / Links
 QuakeML  GSE2.0  Alert  .phi


  Station data

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
EVRHL22.0 25 P10:51:38.32 -0.81.0M
EVRHL22.0 25 S10:51:42.67 0.21.0M
ANXHP24.6130 P10:51:40.31 0.81.0M
ANXHP24.6130 S10:51:43.85 0.61.0M
VVKHP36.2165 P10:51:41.91 0.41.0M
VVKHP36.2165 S10:51:46.70 -0.11.0M
AGRPCL37.9178 P10:51:41.55 -0.21.0M
AGRPCL37.9178 S10:51:46.53 -0.71.0M
EFPHP38.6153 P10:51:42.37 0.51.0M
EFPHP38.6153 S10:51:47.34 -0.11.0M
GR241Y42.8 97 P10:51:43.55 0.91.0M
GR241Y42.8 97 S10:51:49.07 0.21.0M
PLEVHP44.4216 P10:51:42.27 -0.61.0M
PLEVHP44.4216 S10:51:47.62 -1.51.0M
SERGHP47.2140 P10:51:43.43 0.11.0M
SERGHP47.2140 S10:51:49.93 -0.11.0M
AMPLHP47.3296 P10:51:43.54 0.21.0M
ROD3CL50.4161 P10:51:43.74 -0.11.0M
ROD3CL50.4161 S10:51:50.63 -0.21.0M
TRIZCL52.2142 P10:51:44.16 0.11.0M
TRIZCL52.2142 S10:51:51.33 0.01.0M


  Solution details

Event:
    Public ID              nkua2023sjru
    Description
      region name: Greece
Origin:
    Date                   2023-09-19
    Time                  10:51:34.60
    Latitude              38.7365 deg  +/-      1 km
    Longitude             21.7048 deg  +/-      1 km
    Depth                       4 km   +/-    3 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.42 s
    Azimuthal gap              89 deg

2 Network magnitudes:
    MLv       1.19 +/- 0.11   8
    M         1.19            8 preferred

21 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    EVR   HL    0.2  25  P       10:51:38.32  -0.8 M  1.0  EVR
    EVR   HL    0.2  25  S       10:51:42.67   0.2 M  1.0  EVR
    ANX   HP    0.2 130  P       10:51:40.31   0.8 M  1.0  ANX
    ANX   HP    0.2 130  S       10:51:43.85   0.6 M  1.0  ANX
    VVK   HP    0.3 165  P       10:51:41.91   0.4 M  1.0  VVK
    VVK   HP    0.3 165  S       10:51:46.70  -0.1 M  1.0  VVK
    AGRP  CL    0.3 178  P       10:51:41.55  -0.2 M  1.0  AGRP
    AGRP  CL    0.3 178  S       10:51:46.53  -0.7 M  1.0  AGRP
    EFP   HP    0.3 153  P       10:51:42.37   0.5 M  1.0  EFP
    EFP   HP    0.3 153  S       10:51:47.34  -0.1 M  1.0  EFP
    GR24  1Y    0.4  97  P       10:51:43.55   0.9 M  1.0  GR24
    GR24  1Y    0.4  97  S       10:51:49.07   0.2 M  1.0  GR24
    PLEV  HP    0.4 216  P       10:51:42.27  -0.6 M  1.0  PLEV
    PLEV  HP    0.4 216  S       10:51:47.62  -1.5 M  1.0  PLEV
    SERG  HP    0.4 140  P       10:51:43.43   0.1 M  1.0  SERG
    SERG  HP    0.4 140  S       10:51:49.93  -0.1 M  1.0  SERG
    AMPL  HP    0.4 296  P       10:51:43.54   0.2 M  1.0  AMPL
    ROD3  CL    0.5 161  P       10:51:43.74  -0.1 M  1.0  ROD3
    ROD3  CL    0.5 161  S       10:51:50.63  -0.2 M  1.0  ROD3
    TRIZ  CL    0.5 142  P       10:51:44.16   0.1 M  1.0  TRIZ
    TRIZ  CL    0.5 142  S       10:51:51.33  -0.0 M  1.0  TRIZ

10 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    EVR   HL    0.2  25  MLv     1.08 -0.11   0.270455
    ANX   HP    0.2 130  MLv     1.12 -0.08   0.251711
    VVK   HP    0.3 165  MLv     0.80 -0.39   0.291416
    AGRP  CL    0.3 178  MLv     1.43  0.24   0.243678
    EFP   HP    0.3 153  MLv     1.19 -0.00    0.13291
    GR24  1Y    0.4  97  MLv     1.13 -0.06   0.0918213
    PLEV  HP    0.4 216  MLv     1.20  0.01   0.0976489
    SERG  HP    0.4 140  MLv     1.67  0.48   0.246072
    AMPL  HP    0.4 296  MLv     1.13 -0.07   0.069782
    TRIZ  CL    0.5 142  MLv     1.30  0.11   0.0784835
