Earthquake Information
 Origin Time
 2023-09-18 18:23:15 (GMT)
 Magnitude
 M 1.3
 Latitude
 38.3553° N
 Longitude
 21.8437° E
 Focal Depth
 10 km
 # of Arrivals
 34
 Location 15.6 km NE of Patras
23.9 km WNW of Aegion
170.3 km WNW of Athens
 Solution type
 manual
 Files / Links
 QuakeML  GSE2.0  Alert  .phi


  Station data

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
VVKHP7.9339 P18:23:17.25 -0.11.0M
VVKHP7.9339 S18:23:19.10 -0.11.0M
UPRHP9.4212 P18:23:17.41 0.01.0M
UPRHP9.4212 S18:23:19.24 -0.11.0M
EFPHP9.6 34 P18:23:17.48 0.11.0M
EFPHP9.6 34 S18:23:19.40 0.01.0M
AGRPCL11.5293 P18:23:17.68 0.01.0M
AGRPCL11.5293 S18:23:19.78 -0.11.0M
PATCHL12.0217 P18:23:17.94 0.21.0M
PATCHL12.0217 S18:23:20.26 0.31.0M
LAKAHA17.4137 P18:23:18.49 -0.11.0M
LAKAHA17.4137 S18:23:21.13 -0.31.0M
TRIZCL20.0 87 P18:23:19.10 0.21.0M
TRIZCL20.0 87 S18:23:22.10 0.11.0M
KALEHA26.1 81 P18:23:20.02 0.01.0M
KALEHA26.1 81 S18:23:23.76 -0.11.0M
ANXHP27.3 14 P18:23:20.39 0.21.0M
ANXHP27.3 14 S18:23:24.17 -0.11.0M
PLEVHP38.6279 P18:23:21.80 -0.11.0M
PLEVHP38.6279 S18:23:27.35 0.01.0M
PVOHP40.1316 P18:23:22.67 0.51.0M
PVOHP40.1316 S18:23:27.63 -0.11.0M
DROHP46.3195 P18:23:23.28 0.11.0M
DROHP46.3195 S18:23:29.64 0.01.0M
GR241Y48.0 40 P18:23:23.56 0.01.0M
GR241Y48.0 40 S18:23:30.25 0.11.0M
DSFHP59.9 84 P18:23:25.10 -0.41.0M
DSFHP59.9 84 S18:23:33.47 -0.11.0M
GURHP63.8137 P18:23:25.99 -0.11.0M
GURHP63.8137 S18:23:34.49 -0.21.0M
GR291Y72.7175 P18:23:27.42 -0.11.0M
GR291Y72.7175 S18:23:37.05 0.01.0M
ELATHL87.8 70 P18:23:30.24 0.41.0M
ELATHL87.8 70 S18:23:41.57 0.31.0M


  Solution details

Event:
    Public ID              nkua2023sile
    Description
      region name: Greece
Origin:
    Date                   2023-09-18
    Time                  18:23:14.85
    Latitude              38.3553 deg  +/-      0 km
    Longitude             21.8437 deg  +/-      0 km
    Depth                      10 km   +/-    0 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.15 s
    Azimuthal gap              62 deg

2 Network magnitudes:
    MLv       1.29 +/- 0.28  13
    M         1.29           13 preferred

34 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    VVK   HP    0.1 339  P       18:23:17.25  -0.1 M  1.0  VVK
    VVK   HP    0.1 339  S       18:23:19.10  -0.1 M  1.0  VVK
    UPR   HP    0.1 212  P       18:23:17.41   0.0 M  1.0  UPR
    UPR   HP    0.1 212  S       18:23:19.24  -0.1 M  1.0  UPR
    EFP   HP    0.1  34  P       18:23:17.48   0.1 M  1.0  EFP
    EFP   HP    0.1  34  S       18:23:19.40   0.0 M  1.0  EFP
    AGRP  CL    0.1 293  P       18:23:17.68  -0.0 M  1.0  AGRP
    AGRP  CL    0.1 293  S       18:23:19.78  -0.1 M  1.0  AGRP
    PATC  HL    0.1 217  P       18:23:17.94   0.2 M  1.0  PATC
    PATC  HL    0.1 217  S       18:23:20.26   0.3 M  1.0  PATC
    LAKA  HA    0.2 137  P       18:23:18.49  -0.1 M  1.0  LAKA
    LAKA  HA    0.2 137  S       18:23:21.13  -0.3 M  1.0  LAKA
    TRIZ  CL    0.2  87  P       18:23:19.10   0.2 M  1.0  TRIZ
    TRIZ  CL    0.2  87  S       18:23:22.10   0.1 M  1.0  TRIZ
    KALE  HA    0.2  81  P       18:23:20.02   0.0 M  1.0  KALE
    KALE  HA    0.2  81  S       18:23:23.76  -0.1 M  1.0  KALE
    ANX   HP    0.2  14  P       18:23:20.39   0.2 M  1.0  ANX
    ANX   HP    0.2  14  S       18:23:24.17  -0.1 M  1.0  ANX
    PLEV  HP    0.3 279  P       18:23:21.80  -0.1 M  1.0  PLEV
    PLEV  HP    0.3 279  S       18:23:27.35   0.0 M  1.0  PLEV
    PVO   HP    0.4 316  P       18:23:22.67   0.5 M  1.0  PVO
    PVO   HP    0.4 316  S       18:23:27.63  -0.1 M  1.0  PVO
    DRO   HP    0.4 195  P       18:23:23.28   0.1 M  1.0  DRO
    DRO   HP    0.4 195  S       18:23:29.64   0.0 M  1.0  DRO
    GR24  1Y    0.4  40  P       18:23:23.56  -0.0 M  1.0  GR24
    GR24  1Y    0.4  40  S       18:23:30.25   0.1 M  1.0  GR24
    DSF   HP    0.5  84  P       18:23:25.10  -0.4 M  1.0  DSF
    DSF   HP    0.5  84  S       18:23:33.47  -0.1 M  1.0  DSF
    GUR   HP    0.6 137  P       18:23:25.99  -0.1 M  1.0  GUR
    GUR   HP    0.6 137  S       18:23:34.49  -0.2 M  1.0  GUR
    GR29  1Y    0.7 175  P       18:23:27.42  -0.1 M  1.0  GR29
    GR29  1Y    0.7 175  S       18:23:37.05  -0.0 M  1.0  GR29
    ELAT  HL    0.8  70  P       18:23:30.24   0.4 M  1.0  ELAT
    ELAT  HL    0.8  70  S       18:23:41.57   0.3 M  1.0  ELAT

17 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    VVK   HP    0.1 339  MLv     0.91 -0.38    1.91739
    UPR   HP    0.1 212  MLv     0.63 -0.66    2.25553
    EFP   HP    0.1  34  MLv     0.95 -0.35   0.403263
    AGRP  CL    0.1 293  MLv     1.40  0.10    1.02067
    PATC  HL    0.1 217  MLv     1.72  0.43    2.09298
    LAKA  HA    0.2 137  MLv     0.80 -0.49    0.18507
    TRIZ  CL    0.2  87  MLv     1.35  0.06   0.559195
    KALE  HA    0.2  81  MLv     1.06 -0.23   0.201639
    ANX   HP    0.2  14  MLv     1.09 -0.20   0.204115
    PLEV  HP    0.3 279  MLv     0.99 -0.31   0.0838222
    PVO   HP    0.4 316  MLv     1.35  0.06   0.178695
    DRO   HP    0.4 195  MLv     1.24 -0.05   0.200069
    GR24  1Y    0.4  40  MLv     1.46  0.17    0.14458
    DSF   HP    0.5  84  MLv     1.56  0.27   0.0921519
    GUR   HP    0.6 137  MLv     2.00  0.71   0.239586
    GR29  1Y    0.7 175  MLv     1.73  0.44   0.116589
    ELAT  HL    0.8  70  MLv     2.02  0.73   0.192117
