Earthquake Information
 Origin Time
 2023-11-30 20:32:32 (GMT)
 Magnitude
 M 1.9
 Latitude
 39.7483° N
 Longitude
 20.4152° E
 Focal Depth
 6 km
 # of Arrivals
 26
 Location 30.0 km NNE of Igoumenitsa
38.3 km WNW of Ioannina
347.9 km NW of Athens
 Solution type
 manual
 Files / Links
 QuakeML  GSE2.0  Alert  .phi


  Station data

StationNetDist.(km)Azim.PhaseArr.TimeRes.Wgt.Type
GR141Y21.9 40 P20:32:36.50 0.11.0M
GR141Y21.9 40 S20:32:39.42 -0.31.0M
IGTHT25.2197 P20:32:36.84 -0.11.0M
IGTHT25.2197 S20:32:40.32 -0.31.0M
GR19B1Y51.3222 P20:32:41.87 0.61.0M
GR19B1Y51.3222 S20:32:48.19 -0.11.0M
KEKHL53.1266 P20:32:41.90 0.31.0M
KEKHL53.1266 S20:32:48.35 -0.51.0M
GR151Y58.0 68 P20:32:42.37 -0.11.0M
GR151Y58.0 68 S20:32:49.61 -0.81.0M
KPROHT84.1 74 P20:32:46.36 -0.41.0M
KPROHT84.1 74 S20:32:57.37 -0.61.0M
TETRHL86.3121 P20:32:46.72 -0.41.0M
TETRHL86.3121 S20:32:57.79 -0.81.0M
LKD2HT108.7169 P20:32:50.61 0.11.0M
LKD2HT108.7169 S20:33:04.44 -0.21.0M
NYDRHT117.6168 P20:32:52.20 0.31.0M
NYDRHT117.6168 S20:33:07.01 0.01.0M
EVGIHT127.1171 P20:32:54.22 0.81.0M
EVGIHT127.1171 S20:33:09.82 0.21.0M
GR201Y127.7116 P20:32:53.73 0.11.0M
GR201Y127.7116 S20:33:09.92 -0.21.0M
GR101Y129.3 51 P20:32:54.81 0.91.0M
GR101Y129.3 51 S20:33:10.66 0.11.0M
TYRNHT155.5 92 P20:32:58.14 0.31.0M
TYRNHT155.5 92 S20:33:18.38 0.91.0M


  Solution details

Event:
    Public ID              nkua2023xlze
    Description
      region name: Greece-Albania Border Region
Origin:
    Date                   2023-11-30
    Time                  20:32:32.04
    Latitude              39.7483 deg  +/-      1 km
    Longitude             20.4152 deg  +/-      1 km
    Depth                       6 km   +/-    2 km
    Agency                 HA
    Author                 A. Karakonstantis
    Mode                   manual
    Status                 confirmed
    Residual RMS             0.43 s
    Azimuthal gap             134 deg

2 Network magnitudes:
    MLv       1.86 +/- 0.12  11
    M         1.86           11 preferred

26 Phase arrivals:
    sta  net   dist azi  phase   time          res     wt  sta
    GR14  1Y    0.2  40  P       20:32:36.50   0.1 M  1.0  GR14
    GR14  1Y    0.2  40  S       20:32:39.42  -0.3 M  1.0  GR14
    IGT   HT    0.2 197  P       20:32:36.84  -0.1 M  1.0  IGT
    IGT   HT    0.2 197  S       20:32:40.32  -0.3 M  1.0  IGT
    GR19B 1Y    0.5 222  P       20:32:41.87   0.6 M  1.0  GR19B
    GR19B 1Y    0.5 222  S       20:32:48.19  -0.1 M  1.0  GR19B
    KEK   HL    0.5 266  P       20:32:41.90   0.3 M  1.0  KEK
    KEK   HL    0.5 266  S       20:32:48.35  -0.5 M  1.0  KEK
    GR15  1Y    0.5  68  P       20:32:42.37  -0.1 M  1.0  GR15
    GR15  1Y    0.5  68  S       20:32:49.61  -0.8 M  1.0  GR15
    KPRO  HT    0.8  74  P       20:32:46.36  -0.4 M  1.0  KPRO
    KPRO  HT    0.8  74  S       20:32:57.37  -0.6 M  1.0  KPRO
    TETR  HL    0.8 121  P       20:32:46.72  -0.4 M  1.0  TETR
    TETR  HL    0.8 121  S       20:32:57.79  -0.8 M  1.0  TETR
    LKD2  HT    1.0 169  P       20:32:50.61   0.1 M  1.0  LKD2
    LKD2  HT    1.0 169  S       20:33:04.44  -0.2 M  1.0  LKD2
    NYDR  HT    1.1 168  P       20:32:52.20   0.3 M  1.0  NYDR
    NYDR  HT    1.1 168  S       20:33:07.01  -0.0 M  1.0  NYDR
    EVGI  HT    1.1 171  P       20:32:54.22   0.8 M  1.0  EVGI
    EVGI  HT    1.1 171  S       20:33:09.82   0.2 M  1.0  EVGI
    GR20  1Y    1.2 116  P       20:32:53.73   0.1 M  1.0  GR20
    GR20  1Y    1.2 116  S       20:33:09.92  -0.2 M  1.0  GR20
    GR10  1Y    1.2  51  P       20:32:54.81   0.9 M  1.0  GR10
    GR10  1Y    1.2  51  S       20:33:10.66   0.1 M  1.0  GR10
    TYRN  HT    1.4  92  P       20:32:58.14   0.3 M  1.0  TYRN
    TYRN  HT    1.4  92  S       20:33:18.38   0.9 M  1.0  TYRN

13 Station magnitudes:
    sta  net   dist azi  type   value   res        amp per
    GR14  1Y    0.2  40  MLv     1.84 -0.02    1.55695
    IGT   HT    0.2 197  MLv     1.75 -0.11    1.04812
    GR19B 1Y    0.5 222  MLv     2.36  0.50   0.953783
    KEK   HL    0.5 266  MLv     1.56 -0.30   0.259204
    GR15  1Y    0.5  68  MLv     1.85 -0.01   0.199161
    KPRO  HT    0.8  74  MLv     1.83 -0.03   0.128662
    TETR  HL    0.8 121  MLv     1.97  0.11    0.17337
    LKD2  HT    1.0 169  MLv     2.04  0.18   0.157432
    NYDR  HT    1.1 168  MLv     1.74 -0.13   0.0512638
    EVGI  HT    1.1 171  MLv     2.09  0.22   0.141414
    GR20  1Y    1.2 116  MLv     1.75 -0.11   0.0654894
    GR10  1Y    1.2  51  MLv     1.74 -0.13   0.0615298
    TYRN  HT    1.4  92  MLv     1.96  0.10   0.0597548
